Profile 40×80 – 6 Ways Heavy

Code:
BPRDD0000121
Old Code:
01.4080.P6A
Serie:
40
Area:
1558 mm2
Bar length:
6100 mm
Materiale:
Alloy EN AW 6060
Modulo di resistenza:
13,006 Wx/cm3 – 24,555 Wy/cm3
Moment of inertia:
26,011 Jx/cm4 – 98,219 Jy/cm4
Weight:
4,214 kg/ml
Profilo 40×80 – 6 cave pesante - BPRDD0000121
Profilo 40×80 – 6 cave pesante
Profilo 40×80 – 6 cave pesante
Cad 2D Cad 3D
